WH260-RL Digital Hot Plate Magnetic Stirrer

Description:

All functions can be viewed and monitored on a large and clear LCD display, including most frequently used parameters like working temperature, stirring speed, working time, and safety temperature etc.
* Memory function for stirring speed and temperature setting, convenient for experiments with fixed conditions.
* Liquid drainage above the control board to prevent liquids from accessing the touching board and the electronics.
* Direct connection for Pt100 temperature sensor for convenient solution temperature control.
* Sealed outer shell and isolated critical parts design for enhanced longevity even in a harsh laboratory environment.
* High safety protection: When exceeding the safety range of the hotplate (10-50 ℃ adjustable) , the heating can be shut off immediately and automatically for the safety protection.
* 3 sets of PID parameters, suitable for accurate control of small amount sample(small volume or specific heat), and quick heating and stable temperature of large volume sample.

Technical Data:

Maximum temperature setting [℃ ]  450
Maximum temperature setting with E-sensor [℃ ]  300
Safety temperature [℃ ]  50~500 adjustable
High temperature protection [℃ ]  10~50 adjustable
Temperature stability with E-sensor [℃ ]  ±1
Heat output [W]  800
External temperature sensor  Pt100
PID parameter  3 sets
Speed setting range [rpm]  100~1500
Stirring quantity max [L / H2O] 20L
Temperature and Speed display  LCD display
Temperature and Speed setting  Turning knob
Time setting  1~1999min / continuous
Top plate material  Ceramic glass
Top plate dimensions [mm]  Ø145
USB-A interface  Yes
Dimensions W x D x H [mm]  320X190X90
Weight [kg]  3.0
Power supply  220V/50Hz
