AREX 6 Connect Pro Hot Plate Stirrer
Description;
The AREX 6 Connect PRO is provided of 2 independent safety circuits that switch-off the heat preventing possible hazard in all cases of overtemperature (higher than the set point).
When the plate temperature is 50°C the display will show a residual hot plate message preventing potential burning.
The probe detection alarm of the AREX 6 Connect PRO detects that the external probe is not immersed in the medium and stops the heat preserving the sample from burning.
Technical Data;
Velp Ermes Connection | Yes |
User Interface | Digital |
Connectivity | Cloud via Wi-Fi |
Motor | Brushless |
Plate Material | CerAlTop (ceramic coated aluminum alloy) |
Plate Diameter | 135 mm |
Stirring Volume (H2O) | Up to 20 L |
Stirring Speed Range | 30 – 1700 rpm |
Speed Accuracy | 5 rpm |
Speed Control | Digital |
Torque Compensation | SpeedServo |
Heating Control | Digital |
Temperature Range | Room Temp. - 370 °C |
Heat Setting Resolution | 1 °C |
External Digital Thermoregulators Connect | VTF |
External Probe Connection | Pt100 |
Medium Heat Control Accuracy | ± 0,5 °C (VTF) ± 1 °C (PT100) |
Timer | Yes |
Auto-Reverse | Yes |
Probe Detector | Yes |
Lock Of The Intstrument | Yes |
Protection Class | IP42 |
On/Off Safety-Heating-Switch | Yes |
Hot Top Warning System | On Display |
Power Input | 630 W |
Permissible Ambient Temperature | 5 – 40 °C |
Weight | 2.6 kg ( 5.7 Ib) |
Dimensions (WxHxD) | 160x105x280 mm (6.5x4.1x11 in) |
